LBN 174
------------------------------
This region is right next to (and overlaps) my image of LBN 182 / WR 134 seen here: https://www.astrofoto.ca/stuartheggie/ccd_photos/LBN_182_HOO+RGB_AP155_G4_Aug2024.html

Notably, the Tulip Nebula is at the bottom.
------------------------------

Camera: Moravian G4 w Astrodon Gen II LRGB filters
Scope: Astro-Physics AP155EDF w 4" FF
Mount: SB Paramount MX
Guiding: SBIG ST402ME on Borg 60 guidescope
14/14/14 x 10min each for RGB
26 x 20min H-Alpha; 25x20min OIII
Total exposure: 24 hours !!!
Lucknow, Ontario, Canada
Aug 2024
Images captured with TheSkyX
Session orchestrated by CCD-Commander
Calibration and processing of the RGB and Ha and OIII in PixInsight as follows:
RGB: SPCC, BlurX, NoiseX, Gradient, Curves, HistogramTransform
Ha and OIII: BlurX, NoiseX, StarX, Curves and HT and LHE
Ha / OIII combine with their respective stars done via the Foraxx script in PI

Photoshop processing:
Split channels: Added the Starless Ha to Red at 100% and Blue at 20% using Lighten Blend mode. Added the starless OIII to Green and Blue using Lighten at 50% then Selective Colour and Curves adjustments.
The HOO image from PI was also used. I layered the RGB over that using Lighten and some subsequent adjustment layers.
Small tweaks and small noise reduction then Save-for-Web
